Buck Regulator Positive Output Step-Down DC-DC Controller IC 14-MFPS
LV5768M-TLM-H-SY
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Sanyo |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Output Type | Transistor Driver |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 8.5V ~ 42V |
| Frequency - Switching | 80kHz ~ 500kHz |
| Duty Cycle (Max) | 90% |
| Synchronous Rectifier | Yes |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Current Limit, Enable, Frequency Control, Soft Start |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 14-LSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 14-MFPS |
| Base Product Number | LV5768 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | LV5768M-TLM-H | LV5768M-MPB-H | LV5768MZ-TLM-H | LV5768V-A-MPB-E |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ROHS3 Compliant | |||
| Description | IC REG CTRLR BUCK 14-MFPS | IC REG CTRLR BUCK 14-MFPS | IC REG CTRLR BUCK 14-MFPS | IC REG CTRLR BUCK 16SSOP |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tube | Bulk | Tube |
