M054ZDN
lmages are for reference only.M054ZDN
IC MCU 32BIT 16KB FLASH 33QFN
Datasheet32-WFQFN Exposed Pad
97,244 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
ARM® Cortex®-M0 - Microcontroller IC 32-Bit Single-Core 50MHz 16KB (16K x 8) FLASH 33-QFN (5x5)
M054ZDN
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Nuvoton Technology Corporation |
| Series | - |
| Packaging | Tray |
| RoHS Status | |
| Core Processor | ARM® Cortex®-M0 |
| Core Size | 32-Bit Single-Core |
| Speed | 50MHz |
| Connectivity | EBI/EMI, I2C, IrDA, LINbus, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, LVR, POR, PWM, WDT |
| Number of I/O | 24 |
| Program Memory Size | 16KB (16K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 4K x 8 |
| RAM Size | 4K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.5V ~ 5.5V |
| Data Converters | A/D 5x12b SAR |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 33-QFN (5x5) |
| Package / Case | 32-WFQFN Exposed Pad |
| Base Product Number | M054 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | M054ZDE | M054LAN | M054LBN | M054LDE |
| Manufacturer | Nuvoton Technology Corporation | Nuvoton Technology Corporation | Nuvoton Technology Corporation | Nuvoton Technology Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | IC MCU 32BIT 16KB FLASH 33QFN | IC MCU 32BIT 16KB FLASH 48LQFP | IC MCU 32BIT 16KB FLASH 48LQFP | IC MCU 32BIT 16KB FLASH 48LQFP |
| Series | Nuvoton Technology Corporation | Nuvoton Technology Corporation | Nuvoton Technology Corporation | Nuvoton Technology Corporation |
| Packaging | Tray | Tray | Tray | Tray |
