Product CatalogPart Number
M20-8771642P
Manufacturer
Harwin Inc.Description
CONN HEADER SMD 16POS 2.54MM
Datasheet
DatasheetPackage
-
In Stock
22,890 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
M20-8771642P
M20-8771642P
lmages are for reference only.Payment Methods
Delivery Services
Connector Header Surface Mount 16 position 0.100" (2.54mm)
Quick Inquiry
M20-8771642P
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Headers-Male Pins |
| Manufacturer | Harwin Inc. |
| Series | M20 |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Header, Cuttable |
| Contact Type | Male Pin |
| Pitch - Mating | 0.100" (2.54mm) |
| Number of Positions | 16 |
| Number of Rows | 1 |
| Row Spacing - Mating | - |
| Number of Positions Loaded | All |
| Style | Board to Board or Cable |
| Shrouding | Unshrouded |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Fastening Type | Push-Pull |
| Contact Length - Mating | 0.228" (5.80mm) |
| Contact Length - Post | - |
| Overall Contact Length | - |
| Insulation Height | 0.100" (2.54mm) |
| Contact Shape | Square |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | - |
| Contact Finish - Post | Tin |
| Contact Material | Brass |
| Insulation Material | Polyamide (PA6T), Nylon 6T |
| Features | Pick and Place |
| Operating Temperature | -40°C ~ 105°C |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Insulation Color | Black |
| Current Rating (Amps) | 3A per Contact |
| Voltage Rating | - |
| Mated Stacking Heights | 11.63mm, 12.23mm, 12.63mm, 18.13mm |
| Contact Finish Thickness - Post | - |
| Applications | - |
| Base Product Number | M20-877 |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | M20-8771642 | M20-8771642R | M20-8750242 | M20-8750242R |
| Manufacturer | Harwin Inc. | Harwin Inc. | Harwin Inc. | Harwin Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CONN HEADER SMD 16POS 2.54MM | CONN HEADER SMD 16POS 2.54MM | CONN HEADER SMD 4POS 2.54MM | CONN HEADER SMD 4POS 2.54MM |
| Series | M20 | M20 | M20 | M20 |
| Packaging | Bulk | Tape & Reel (TR) | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
