Product CatalogPart Number
M22-5321846
Manufacturer
Harwin Inc.Description
CONN HEADER SMD 36POS 2MM
Datasheet
DatasheetPackage
-
In Stock
77,041 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
M22-5321846
M22-5321846
lmages are for reference only.Payment Methods
Delivery Services
Connector Header Surface Mount 36 position 0.079" (2.00mm)
Quick Inquiry
M22-5321846
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Headers-Male Pins |
| Manufacturer | Harwin Inc. |
| Series | M22 |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Header, Cuttable |
| Contact Type | Male Pin |
| Pitch - Mating | 0.079" (2.00mm) |
| Number of Positions | 36 |
| Number of Rows | 2 |
| Row Spacing - Mating | 0.079" (2.00mm) |
| Number of Positions Loaded | All |
| Style | Board to Board |
| Shrouding | Unshrouded |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Fastening Type | Push-Pull |
| Contact Length - Mating | 0.138" (3.50mm) |
| Contact Length - Post | - |
| Overall Contact Length | - |
| Insulation Height | 0.059" (1.50mm) |
| Contact Shape | Square |
| Contact Finish - Mating | Tin |
| Contact Finish Thickness - Mating | - |
| Contact Finish - Post | Tin |
| Contact Material | Phosphor Bronze |
| Insulation Material | Polyamide (PA6T), Nylon 6T |
| Features | - |
| Operating Temperature | -40°C ~ 105°C |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Insulation Color | Black |
| Current Rating (Amps) | 1A per Contact |
| Voltage Rating | - |
| Mated Stacking Heights | 4.6mm, 6.8mm |
| Contact Finish Thickness - Post | - |
| Applications | - |
| Base Product Number | - |
