Product CatalogPart Number
M3SWA2-63DRC+
Manufacturer
Mini-CircuitsDescription
IC RF SWITCH SPDT 6GHZ 12MCLP
Datasheet
DatasheetPackage
12-VQFN Exposed Pad
In Stock
16,295 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
M3SWA2-63DRC+
M3SWA2-63DRC+
lmages are for reference only.Payment Methods
Delivery Services
RF Switch IC General Purpose SPDT 50Ohm 12-MCLP (3x3)
Quick Inquiry
M3SWA2-63DRC+
Specifications
| Category | RF and Wireless - RF Switches - |
| Manufacturer | Mini-Circuits |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| RF Type | General Purpose |
| Topology | Absorptive |
| Circuit | SPDT |
| Frequency Range | DC ~ 6GHz |
| Isolation | 32dB |
| Insertion Loss | 1.3dB |
| Test Frequency | 6GHz |
| P1dB | 25.6dBm |
| IIP3 | 43.8dBm |
| Features | DC Blocked |
| Impedance | 50Ohm |
| Voltage - Supply | 4.75V ~ 5.25V |
| Operating Temperature | -55°C ~ 100°C |
| Package / Case | 12-VQFN Exposed Pad |
| Supplier Device Package | 12-MCLP (3x3) |
| Base Product Number | M3SWA2 |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
