Product CatalogPart Number
M40-6001546R
Manufacturer
Harwin Inc.Description
CONN PLUG 15POS SMD TIN
Datasheet
DatasheetPackage
-
In Stock
33,093 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
M40-6001546R
M40-6001546R
lmages are for reference only.Payment Methods
Delivery Services
15 Position Connector Plug, Center Strip Contacts Surface Mount Tin
Quick Inquiry
M40-6001546R
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Arrays-Edge Type-Mezzanine Board to Board |
| Manufacturer | Harwin Inc. |
| Series | M40 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Plug, Center Strip Contacts |
| Number of Positions | 15 |
| Pitch | 0.039" (1.00mm) |
| Number of Rows | 2 |
| Mounting Type | Surface Mount |
| Features | Board Guide, Solder Retention |
| Contact Finish | Tin |
| Contact Finish Thickness | 80.0µin (2.03µm) |
| Mated Stacking Heights | - |
| Height Above Board | 0.130" (3.30mm) |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | M40-6001546 | M40-6000946 | M40-6000946R | M40-6002146 |
| Manufacturer | Harwin Inc. | Harwin Inc. | Harwin Inc. | Harwin Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CONN PLUG 15POS SMD TIN | CONN PLUG 9POS SMD TIN | CONN PLUG 9POS SMD TIN | CONN PLUG 21POS SMD TIN |
| Series | M40 | M40 | M40 | M40 |
| Packaging | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
