M80-4201801

M80-4201801

M80-4201801

lmages are for reference only.
  • Part Number

    M80-4201801

  • Manufacturer

    Harwin Inc.
  • Description

    CONN RCPT 18POS 0.079 GOLD PCB

  • Datasheet

    DatasheetDatasheet
  • Package

    -

  • In Stock

    91,089 piece(s)

  • Unit Price

    Please Contact Us

  • Lead Time

    Can Ship Immediately

Request for Quotation

  • Payment Methods

  • Delivery Services

18 Position Receptacle Connector 0.079" (2.00mm) Through Hole Gold

Quick Inquiry

M80-4201801

Get the Price Now!

Specifications

Category Connectors, Interconnects - Rectangular Connectors - Headers-Receptacles-Female Sockets
Manufacturer Harwin Inc.
Series Datamate J-Tek
Packaging Tube
RoHS Status RoHS non-compliant
Connector Type Receptacle
Contact Type Female Socket
Style Board to Board or Cable
Number of Positions 18
Number of Positions Loaded All
Pitch - Mating 0.079" (2.00mm)
Number of Rows 2
Row Spacing - Mating 0.079" (2.00mm)
Mounting Type Through Hole
Termination Solder
Fastening Type Screw Lock
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 12.0µin (0.30µm)
Insulation Color Black
Insulation Height 0.205" (5.20mm)
Contact Length - Post 0.118" (3.00mm)
Operating Temperature -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Contact Finish - Post Tin-Lead
Mated Stacking Heights 7.3mm, 7.55mm
Ingress Protection -
Features Jackscrews, Mating Flange, Mounting Flange, Polarizing Key
Current Rating (Amps) -
Voltage Rating 120V
Applications Automotive, General Purpose, Military
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled
Contact Shape Circular
Contact Material Beryllium Copper
Contact Finish Thickness - Post 137.8µin (3.50µm)
Base Product Number M80-420

Parts with Similar Specifications

Product Attribute M80-4201001 M80-4201005 M80-4201042 M80-4201201
Part Number M80-4201001 M80-4201005 M80-4201042 M80-4201201
Manufacturer Harwin Inc. Harwin Inc. Harwin Inc. Harwin Inc.
RoHS Status RoHS non-compliant ROHS3 Compliant ROHS3 Compliant RoHS non-compliant
Description CONN RCPT 10POS 0.079 GOLD PCB CONN RCPT 10POS 0.079 GOLD PCB CONN RCPT 10POS 0.079 GOLD PCB CONN RCPT 12POS 0.079 GOLD PCB
Series Harwin Inc. Harwin Inc. Harwin Inc. Harwin Inc.
Packaging Tube Tube Tube Tube
