Product CatalogPart Number
M80-4222605
Manufacturer
Harwin Inc.Description
CONN 26POS FEMALE DIL VERT SMD
Datasheet
DatasheetPackage
-
In Stock
33,807 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
M80-4222605
M80-4222605
lmages are for reference only.Payment Methods
Delivery Services
26 Position Receptacle Connector 0.079" (2.00mm) Surface Mount Gold
Quick Inquiry
M80-4222605
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Headers-Receptacles-Female Sockets |
| Manufacturer | Harwin Inc. |
| Series | Datamate J-Tek |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Style | Board to Board or Cable |
| Number of Positions | 26 |
| Number of Positions Loaded | All |
| Pitch - Mating | 0.079" (2.00mm) |
| Number of Rows | 2 |
| Row Spacing - Mating | 0.079" (2.00mm) |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Fastening Type | Screw Lock |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 12.0µin (0.30µm) |
| Insulation Color | Black |
| Insulation Height | 0.220" (5.60mm) |
| Contact Length - Post | - |
| Operating Temperature | -55°C ~ 125°C |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish - Post | Gold |
| Mated Stacking Heights | 7.8mm, 8.05mm |
| Ingress Protection | - |
| Features | Jackscrews, Mating Flange, Mounting Flange, Polarizing Key |
| Current Rating (Amps) | 3A |
| Voltage Rating | 120V |
| Applications | Automotive, General Purpose, Military |
| Insulation Material | Polyphenylene Sulfide (PPS), Glass Filled |
| Contact Shape | Circular |
| Contact Material | Beryllium Copper |
| Contact Finish Thickness - Post | 12.0µin (0.30µm) |
| Base Product Number | M80-422 |
