MAL250119332E3
lmages are for reference only.MAL250119332E3
CAP ALUM 3300UF 20% 500V SCREW
DatasheetRadial, Can - Screw Terminals
95,017 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
3300 µF 500 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 73mOhm @ 100Hz 5000 Hrs @ 85°C
MAL250119332E3
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | Vishay Beyschlag/Draloric/BC Components |
| Series | 501 PGM-ST |
| Packaging | Box |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 3300 µF |
| Tolerance | ±20% |
| Voltage - Rated | 500 V |
| ESR (Equivalent Series Resistance) | 73mOhm @ 100Hz |
| Lifetime @ Temp. | 5000 Hrs @ 85°C |
| Operating Temperature | -25°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 12.6 A @ 100 Hz |
| Ripple Current @ High Frequency | 18.9 A @ 10 kHz |
| Lead Spacing | 1.252" (31.80mm) |
| Size / Dimension | 2.992" Dia (76.00mm) |
| Height - Seated (Max) | - |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Base Product Number | - |
| Impedance | 59 mOhms |
| Product Attribute |  |
 |
 |
 |
| Part Number | MAL250116152E3 | MAL250116153E3 | MAL250116222E3 | MAL250116332E3 |
| Manufacturer | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP ALUM 1500UF 20% 400V SCREW | CAP ALUM 15000UF 20% 400V SCREW | CAP ALUM 2200UF 20% 400V SCREW | CAP ALUM 3300UF 20% 400V SCREW |
| Series | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components |
| Packaging | Box | Box | Box | Box |
