Category |
Integrated Circuits (ICs) - Interface - Analog Switches-Multiplexers-Demultiplexers |
Manufacturer |
Analog Devices Inc./Maxim Integrated |
Series |
- |
Packaging |
Tape & Reel (TR)-->Cut Tape (CT) |
RoHS Status |
ROHS3 Compliant |
Switch Circuit |
SPST - NO |
Multiplexer/Demultiplexer Circuit |
1:1 |
Number of Circuits |
8 |
On-State Resistance (Max) |
1Ohm |
Channel-to-Channel Matching (ΔRon) |
20mOhm |
Voltage - Supply, Single (V+) |
1.6V ~ 5.5V |
Voltage - Supply, Dual (V±) |
- |
Switch Time (Ton, Toff) (Max) |
35µs (Max), 5.5µs (Typ) |
-3db Bandwidth |
400MHz |
Charge Injection |
- |
Channel Capacitance (CS(off), CD(off)) |
- |
Current - Leakage (IS(off)) (Max) |
50nA |
Crosstalk |
-80dB @ 1MHz |
Operating Temperature |
-40°C ~ 85°C (TA) |
Mounting Type |
Surface Mount |
Package / Case |
28-WFQFN Exposed Pad |
Supplier Device Package |
28-TQFN (4x4) |
Base Product Number |
MAX14662 |
Grade |
- |
Qualification |
- |
