RS485 Digital Isolator 5000Vrms 3 Channel 20Mbps 35kV/µs (Typ) CMTI 16-SOIC (0.295", 7.50mm Width)
MAX14941GWE+T
| Category | Isolators - Digital Isolators - |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Technology | Capacitive Coupling |
| Type | RS485 |
| Isolated Power | No |
| Number of Channels | 3 |
| Inputs - Side 1/Side 2 | 2/1 |
| Channel Type | Unidirectional |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 35kV/µs (Typ) |
| Data Rate | 20Mbps |
| Propagation Delay tpLH / tpHL (Max) | 68ns, 68ns |
| Pulse Width Distortion (Max) | - |
| Rise / Fall Time (Typ) | 15ns, 15ns (Max) |
| Voltage - Supply | 1.71V ~ 5.5V, 4.5V ~ 5.5V |
| Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 16-SOIC |
| Base Product Number | MAX14941 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MAX14941GWE+ | MAX14942GWE+ | MAX14942GWE+T | MAX14943GWE+ |
| Manufacturer | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DGTL ISO 5000VRMS RS485 16SOIC | DGTL ISO 5000VRMS RS485 16SOIC | DGTL ISO 5000VRMS RS485 16SOIC | DGTL ISO 5000VRMS RS485 16SOIC |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
