MAX15046CAEE+
lmages are for reference only.MAX15046CAEE+
IC REG CTRLR BUCK 16QSOP
Datasheet16-LSSOP (0.154", 3.90mm Width) Exposed Pad
37,283 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Buck Regulator Positive Output Step-Down DC-DC Controller IC 16-QSOP-EP
MAX15046CAEE+
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Type | Transistor Driver |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 40V |
| Frequency - Switching | 100kHz ~ 1MHz |
| Duty Cycle (Max) | 87.5% |
| Synchronous Rectifier | Yes |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Current Limit, Enable, Frequency Control, Power Good |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 16-LSSOP (0.154", 3.90mm Width) Exposed Pad |
| Supplier Device Package | 16-QSOP-EP |
| Base Product Number | MAX15046 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MAX15046CAEE+T | MAX15046AAEE+ | MAX15046BAEE+ | MAX15046BAEE+T |
| Manufacturer | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG CTRLR BUCK 16QSOP | IC REG CTRLR BUCK 16QSOP | IC REG CTRLR BUCK 16QSOP | IC REG CTRLR BUCK 16QSOP |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
