MAX22203ATU+T
lmages are for reference only.MAX22203ATU+T
DUAL H-BRIDGE FOR STEPPER AND BR
Datasheet38-WFQFN Exposed Pad
79,309 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bipolar Motor Driver NMOS PWM 38-TQFN (5x7)
MAX22203ATU+T
| Category | Integrated Circuits (ICs) - Power Management PMIC - Motor Drivers-Controllers |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | Brushed DC |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (8) |
| Interface | PWM |
| Technology | NMOS |
| Step Resolution | - |
| Applications | General Purpose |
| Current - Output | 1A |
| Voltage - Supply | 4.5V ~ 36V |
| Voltage - Load | 4.5V ~ 36V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 38-WFQFN Exposed Pad |
| Supplier Device Package | 38-TQFN (5x7) |
| Base Product Number | MAX22203 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | MAX22203ATU+ | MAX22203ATU+ | MAX22203ATU+T | MAX22200ETJ+ |
| Manufacturer | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DUAL H-BRIDGE FOR STEPPER AND BR | DUAL H-BRIDGE FOR STEPPER AND BR | DUAL H-BRIDGE FOR STEPPER AND BR | EIGHT HALF-BRIDGES SERIAL CONTRO |
| Series | - | - | - | - |
| Packaging | Tray | Tray | Tape & Reel (TR) | Tray |
