MC22XS4200CEKR2
lmages are for reference only.MC22XS4200CEKR2
IC PWR SWITCH N-CHAN 1:1 32SOIC
Datasheet32-SSOP (0.295", 7.50mm Width) Exposed Pad
51,917 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Power Switch/Driver 1:1 N-Channel 4.2A 32-SOIC-EP
MC22XS4200CEKR2
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Distribution Switches-Load Drivers |
| Manufacturer | NXP USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Switch Type | General Purpose |
| Number of Outputs | 2 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | SPI |
| Voltage - Load | 8V ~ 36V |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
| Current - Output (Max) | 4.2A |
| Rds On (Typ) | 22mOhm |
| Input Type | - |
| Features | Internal PWM, Slew Rate Controlled |
| Fault Protection | Open Load Detect, Over Temperature |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 32-SOIC-EP |
| Package / Case | 32-SSOP (0.295", 7.50mm Width) Exposed Pad |
| Base Product Number | MC20XS4200 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MC22XS4200CEK | MC22XS4200BEK | MC22XS4200BEKR2 | MC22XS4200DEK |
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC PWR SWITCH N-CHAN 1:1 32SOIC | IC PWR SWITCH N-CHAN 1:2 32HSOP | IC PWR SWITCH N-CHAN 1:2 32HSOP | HIGH-SIDE SWITCH, 24V, DUAL 22MO |
| Series | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Packaging | Tube | Tube | Tape & Reel (TR) | Tube |
