MC5402L
Manufacturer
MotorolaDescription
IC GATE NOR 4CH 2-INP TO116
Datasheet
DatasheetPackage
14-DIP (0.300", 7.62mm)
In Stock
34,880 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MC5402L
MC5402L
lmages are for reference only.Payment Methods
Delivery Services
NOR Gate IC 4 Channel TO-116
Quick Inquiry
MC5402L
Specifications
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | Motorola |
| Series | MC5400L |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Base Product Number | MC5402 |
| Logic Type | NOR Gate |
| Number of Circuits | 4 |
| Number of Inputs | 2 |
| Features | - |
| Voltage - Supply | 4.5V ~ 5.5V |
| Current - Quiescent (Max) | - |
| Current - Output High, Low | 400μA, 16mA |
| Input Logic Level - Low | 0.4V |
| Input Logic Level - High | 2.4V |
| Max Propagation Delay @ V, Max CL | 29ns @ 5V, 50pF |
| Operating Temperature | -55＜C ~ 125＜C |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-116 |
| Package / Case | 14-DIP (0.300", 7.62mm) |
| Grade | - |
| Qualification | - |
