MC56F8322MFAE
Manufacturer
NXP USA Inc.Description
IC MCU 16BIT 32KB FLASH 48LQFP
Datasheet
DatasheetPackage
48-LQFP
In Stock
92,694 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MC56F8322MFAE
MC56F8322MFAE
lmages are for reference only.Payment Methods
Delivery Services
56800E 56F8xxx Microcontroller IC 16-Bit 60MHz 32KB (16K x 16) FLASH 48-LQFP (7x7)
Quick Inquiry
MC56F8322MFAE
Specifications
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | NXP USA Inc. |
| Series | 56F8xxx |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Core Processor | 56800E |
| Core Size | 16-Bit |
| Speed | 60MHz |
| Connectivity | CANbus, SCI, SPI |
| Peripherals | POR, PWM, Temp Sensor, WDT |
| Number of I/O | 21 |
| Program Memory Size | 32KB (16K x 16) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 6K x 16 |
| Voltage - Supply (Vcc/Vdd) | 2.25V ~ 3.6V |
| Data Converters | A/D 6x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 48-LQFP (7x7) |
| Package / Case | 48-LQFP |
| Base Product Number | MC56F83 |
| Grade | - |
| Qualification | - |
