Linear Voltage Regulator IC Positive Fixed 1 Output 1A D2PAK-3
MC7805CD2TG
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 35V |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 2V @ 1A (Typ) |
| Current - Output | 1A |
| Current - Quiescent (Iq) | 6.5 mA |
| PSRR | 83dB (120Hz) |
| Control Features | - |
| Protection Features | Over Temperature, Short Circuit |
| Operating Temperature | 0°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Supplier Device Package | D2PAK-3 |
| Base Product Number | MC7805 |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MC7805CD2T | MC7805CD2TR4 | MC7805CD2TR4G | MC7805CDT |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | IC REG LINEAR 5V 1A D2PAK | IC REG LINEAR 5V 1A D2PAK | IC REG LINEAR 5V 1A D2PAK | IC REG LINEAR 5V 1A DPAK |
| Series | onsemi | onsemi | onsemi | onsemi |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
