MC9S12XHZ256CAL
lmages are for reference only.MC9S12XHZ256CAL
IC MCU 16BIT 256KB FLASH 112LQFP
Datasheet112-LQFP
47,175 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
HCS12X HCS12X Microcontroller IC 16-Bit 50MHz 256KB (256K x 8) FLASH 112-LQFP (20x20)
MC9S12XHZ256CAL
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Freescale Semiconductor |
| Series | HCS12X |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Core Processor | HCS12X |
| Core Size | 16-Bit |
| Speed | 50MHz |
| Connectivity | CANbus, EBI/EMI, I2C, LINbus, SCI, SPI |
| Peripherals | LCD, Motor control PWM, POR, PWM, WDT |
| Number of I/O | 85 |
| Program Memory Size | 256KB (256K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 4K x 8 |
| RAM Size | 16K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.35V ~ 5.5V |
| Data Converters | A/D 16x10b |
| Oscillator Type | External |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 112-LQFP (20x20) |
| Package / Case | 112-LQFP |
| Base Product Number | MC9S12 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | MC9S12XHZ256CAG | MC9S12XHZ256CAL | MC9S12XHZ256VAG | MC9S12XHZ256VAGR |
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC MCU 16BIT 256KB FLASH 144LQFP | IC MCU 16BIT 256KB FLASH 112LQFP | IC MCU 16BIT 256KB FLASH 144LQFP | IC MCU 16BIT 256KB FLASH 144LQFP |
| Series | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Packaging | Tray | Tray | Tray | Tape & Reel (TR) |
