MCACD12NP10YHE3-TP
lmages are for reference only.MCACD12NP10YHE3-TP
MOSFET N/P-CH 100V 40A 8PDFN
Datasheet8-PowerLDFN
42,194 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Mosfet Array 100V 40A (Tc), 12A (Tc) 104W (Tj), 69W (Tj) Surface Mount PDFN5060-8D
MCACD12NP10YHE3-TP
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Technology | MOSFET (Metal Oxide) |
| Configuration | N and P-Channel |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 100V |
| Current - Continuous Drain (Id) @ 25°C | 40A (Tc), 12A (Tc) |
| Rds On (Max) @ Id, Vgs | 24mOhm @ 20A, 10V, 115mOhm @ 12A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 17nC @ 10V, 20nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 1270pF @ 25V, 1120pF @ 25V |
| Power - Max | 104W (Tj), 69W (Tj) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerLDFN |
| Supplier Device Package | PDFN5060-8D |
| Base Product Number | - |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute |  |
 |
 |
 |
| Part Number | MCACD12NP10Y-TP | MCACD033N10YL-TP | MCACD20N06HE3-TP | MCACD20N10Y-TP |
| Manufacturer | Micro Commercial Co | Micro Commercial Co | Micro Commercial Co | Micro Commercial Co |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | MOSFET N/P-CH 100V 25A 8DFN | MOSFET 2N-CH 100V 20A 8PDFN | MOSFET 2N-CH 60V 20A 8PDFN | MOSFET 2N-CH 100V 20A 8DFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Bulk |
