MG06400D-BN1MM
Manufacturer
Littelfuse Inc.Description
IGBT MODULE 600V 460A 1400W D3
Datasheet
DatasheetPackage
D-3 Module
In Stock
23,177 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MG06400D-BN1MM
MG06400D-BN1MM
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module Half Bridge 600 V 460 A 1400 W Chassis Mount D3
Quick Inquiry
MG06400D-BN1MM
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Littelfuse Inc. |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | - |
| Configuration | Half Bridge |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 460 A |
| Power - Max | 1400 W |
| Vce(on) (Max) @ Vge, Ic | 2.45V @ 15V, 400A |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 18 nF @ 25 V |
| Input | Standard |
| NTC Thermistor | No |
| Operating Temperature | - |
| Mounting Type | Chassis Mount |
| Package / Case | D-3 Module |
| Supplier Device Package | D3 |
| Base Product Number | - |
