MGA-545P8-BLK
lmages are for reference only.MGA-545P8-BLK
IC AMP CELLULAR 50MHZ-7GHZ 8LPCC
Datasheet8-WFDFN Exposed Pad
47,777 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RF Amplifier IC Cellular, PCS, WLAN, WLL 50MHz ~ 7GHz 8-LPCC (2x2)
MGA-545P8-BLK
| Category | RF and Wireless - RF Amplifiers - |
| Manufacturer | Broadcom Limited |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Frequency | 50MHz ~ 7GHz |
| P1dB | 21.7dBm |
| Gain | 16.3dB |
| Noise Figure | 2.7dB |
| RF Type | Cellular, PCS, WLAN, WLL |
| Voltage - Supply | 2.7V ~ 4V |
| Current - Supply | 110mA ~ 145mA |
| Test Frequency | 2GHz |
| Mounting Type | Surface Mount |
| Package / Case | 8-WFDFN Exposed Pad |
| Supplier Device Package | 8-LPCC (2x2) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | MGA-545P8-TR1 | MGA-545P8-TR2 | MGA-12516-BLKG | MGA-12516-TR1G |
| Manufacturer | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| RoHS Status | ||||
| Description | IC RF AMP WLL 50MHZ-7GHZ 8LPCC | IC RF AMP WLL 50MHZ-7GHZ 8LPCC | IC RF AMP 16QFN | IC RF AMP 16QFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Bag | Tape & Reel (TR) |
