MIC47100-0.8YML
lmages are for reference only.MIC47100-0.8YML
IC REG LINEAR 1A HI SPEED LO VIN
Datasheet8-VFDFN Exposed Pad, 8-MLF®
12,302 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 1A 8-MLF® (2x2)
MIC47100-0.8YML
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Micrel Inc. |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 3.6V |
| Voltage - Output (Min/Fixed) | 0.8V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.25V @ 1A |
| Current - Output | 1A |
| Current - Quiescent (Iq) | 500 µA |
| PSRR | 80dB ~ 45dB (1kHz ~ 500kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-VFDFN Exposed Pad, 8-MLF® |
| Supplier Device Package | 8-MLF® (2x2) |
| Base Product Number | - |
| Current - Supply (Max) | 500 µA |
| Product Attribute |  |
 |
|
 |
| Part Number | MIC47100-0.8YML-TR | MIC47100-08YMME | MIC47100-08YMME | MIC47100-08YMME-TR |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC REG LINEAR 0.8V 1A 8MLF | IC REG LINEAR 0.8V 1A 8MSOP | IC REG LINEAR 0.8V 1A 8MSOP | IC REG LINEAR 0.8V 1A 8MSOP |
| Series | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Bulk | Tape & Reel (TR) |
