MINI52FDE
lmages are for reference only.MINI52FDE
IC MCU 32BIT 8KB FLASH 20TSSOP
Datasheet20-TSSOP (0.173", 4.40mm Width)
20,708 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
ARM® Cortex®-M0 NuMicro M051™ DE Microcontroller IC 32-Bit Single-Core 24MHz 8KB (8K x 8) FLASH 20-TSSOP
MINI52FDE
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Nuvoton Technology Corporation |
| Series | NuMicro M051™ DE |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Core Processor | ARM® Cortex®-M0 |
| Core Size | 32-Bit Single-Core |
| Speed | 24MHz |
| Connectivity | I2C, IrDA, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, LVD, POR, PWM, WDT |
| Number of I/O | 17 |
| Program Memory Size | 8KB (8K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 2K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.5V ~ 5.5V |
| Data Converters | A/D 4x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 20-TSSOP |
| Package / Case | 20-TSSOP (0.173", 4.40mm Width) |
| Base Product Number | MINI52 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MINI52LAN | MINI52LDE | MINI52TAN | MINI52TDE |
| Manufacturer | Nuvoton Technology Corporation | Nuvoton Technology Corporation | Nuvoton Technology Corporation | Nuvoton Technology Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | IC MCU 32BIT 8KB FLASH 48LQFP | IC MCU 32BIT 8KB FLASH 48LQFP | IC MCU 32BIT 8KB FLASH 32VFQFN | IC MCU 32BIT 8KB FLASH 33QFN |
| Series | Nuvoton Technology Corporation | Nuvoton Technology Corporation | Nuvoton Technology Corporation | Nuvoton Technology Corporation |
| Packaging | Tray | Tray | Tray | Tray |
