MJE13001-AP
lmages are for reference only.MJE13001-AP
TRANS NPN 400V 0.2A TO-92
DatasheetTO-226-3, TO-92-3 (TO-226AA) Formed Leads
57,065 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bipolar (BJT) Transistor NPN 400 V 200 mA 8MHz 1 W Through Hole TO-92
MJE13001-AP
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Tape & Box (TB) |
| RoHS Status | ROHS3 Compliant |
| Transistor Type | NPN |
| Current - Collector (Ic) (Max) | 200 mA |
| Voltage - Collector Emitter Breakdown (Max) | 400 V |
| Vce Saturation (Max) @ Ib, Ic | 500mV @ 10mA, 50mA |
| Current - Collector Cutoff (Max) | 100µA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 10 @ 20mA, 20V |
| Power - Max | 1 W |
| Frequency - Transition | 8MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) Formed Leads |
| Supplier Device Package | TO-92 |
| Base Product Number | MJE13001 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MJE13002-BP | MJE13002B-AP | MJE13003 | MJE13003-BP |
| Manufacturer | Micro Commercial Co | Micro Commercial Co | onsemi | Micro Commercial Co |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | TRANS NPN 400V 1A TO-126 | TRANS NPN 400V 0.8A TO-92 | TRANS NPN 400V 1.5A TO-126 | TRANS NPN 400V 1.5A TO-220AB |
| Series | - | - | SWITCHMODE™ | - |
| Packaging | Bulk | Tape & Box (TB) | Bulk | Tube |
