MKP386M456250YT7
lmages are for reference only.MKP386M456250YT7
CAP FILM 0.56UF 5% 2.5KVDC SCREW
DatasheetRectangular Box
39,479 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
0.56 µF Film Capacitor 800V 2500V (2.5kV) Polypropylene (PP), Metallized Rectangular Box
MKP386M456250YT7
| Category | Capacitors - Film Capacitors - |
| Manufacturer | Vishay Beyschlag/Draloric/BC Components |
| Series | MKP386M |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 0.56 µF |
| Tolerance | ±5% |
| Voltage Rating - AC | 800V |
| Voltage Rating - DC | 2500V (2.5kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -55°C ~ 105°C |
| Mounting Type | Chassis Mount |
| Package / Case | Rectangular Box |
| Size / Dimension | 2.283" L x 1.181" W (58.00mm x 30.00mm) |
| Height - Seated (Max) | 1.772" (45.00mm) |
| Termination | Screw Terminals |
| Lead Spacing | 1.417" (36.00mm) |
| Applications | Snubber |
| Ratings | - |
| Features | Low ESR |
| ESR (Equivalent Series Resistance) | 4.5 mOhms |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MKP386M456250YT1 | MKP386M456250YT2 | MKP386M456250YT3 | MKP386M456250YT4 |
| Manufacturer | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP FILM 0.56UF 5% 2.5KVDC SCREW | CAP FILM 0.56UF 5% 2.5KVDC SCREW | CAP FILM 0.56UF 5% 2.5KVDC SCREW | CAP FILM 0.56UF 5% 2.5KVDC SCREW |
| Series | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components |
| Packaging | Bulk | Bulk | Bulk | Bulk |
