MLX90248ESC-ECA-000-RE
lmages are for reference only.MLX90248ESC-ECA-000-RE
OMNIPOLAR, NON-PROGRAMMABLE.SWIT
DatasheetSC-70, SOT-323
67,185 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Digital Switch Latch, Omnipolar Switch Open Drain Hall Effect SC-70
MLX90248ESC-ECA-000-RE
| Category | Sensors, Transducers - Magnetic Sensors - Switches Solid State |
| Manufacturer | Melexis Technologies NV |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Function | Latch, Omnipolar Switch |
| Technology | Hall Effect |
| Polarization | North Pole, South Pole |
| Sensing Range | ±6mT Trip, ±0.8mT Release |
| Test Condition | 25°C |
| Voltage - Supply | 1.5V ~ 3.6V |
| Current - Supply (Max) | 5mA |
| Current - Output (Max) | 10mA |
| Output Type | Open Drain |
| Features | - |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SC-70 |
| Package / Case | SC-70, SOT-323 |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
|
| Part Number | MLX90248ESC-ECA-000-CN | MLX90248ESC-ECA-000-SP | MLX90248ESC-EBA-000-CN | MLX90248ESC-EBA-000-RE |
| Manufacturer | Melexis Technologies NV | Melexis Technologies NV | Melexis Technologies NV | Melexis Technologies NV |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | OMNIPOLAR, NON-PROGRAMMABLE.SWIT | OMNIPOLAR, NON-PROGRAMMABLE.SWIT | OMNIPOLAR, NON-PROGRAMMABLE.SWIT | OMNIPOLAR, NON-PROGRAMMABLE.SWIT |
| Series | Melexis Technologies NV | Melexis Technologies NV | Melexis Technologies NV | Melexis Technologies NV |
| Packaging | Tape & Reel (TR) | Bulk | Tape & Reel (TR) | Tape & Reel (TR) |
