Product CatalogPart Number
MM74HC02SJX
Manufacturer
onsemiDescription
IC GATE NOR 4CH 2-INP 14SOP
Datasheet
DatasheetPackage
14-SOIC (0.209", 5.30mm Width)
In Stock
38,504 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MM74HC02SJX
MM74HC02SJX
lmages are for reference only.Payment Methods
Delivery Services
NOR Gate IC 4 Channel 14-SOP
Quick Inquiry
MM74HC02SJX
Specifications
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | onsemi |
| Series | 74HC |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Base Product Number | 74HC02 |
| Logic Type | NOR Gate |
| Number of Circuits | 4 |
| Number of Inputs | 2 |
| Features | - |
| Voltage - Supply | 2V ~ 6V |
| Current - Quiescent (Max) | 2 µA |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Input Logic Level - Low | 0.5V ~ 1.8V |
| Input Logic Level - High | 1.5V ~ 4.2V |
| Max Propagation Delay @ V, Max CL | 15ns @ 6V, 50pF |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-SOP |
| Package / Case | 14-SOIC (0.209", 5.30mm Width) |
| Grade | - |
| Qualification | - |
