MMDT3906TB6_R1_00001
lmages are for reference only.MMDT3906TB6_R1_00001
TRANS 2PNP 40V 200MA SOT-563
DatasheetSOT-563, SOT-666
49,419 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bipolar (BJT) Transistor Array 2 PNP (Dual) 40V 200mA 250MHz 200mW Surface Mount SOT-563
MMDT3906TB6_R1_00001
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | Panjit International Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Transistor Type | 2 PNP (Dual) |
| Current - Collector (Ic) (Max) | 200mA |
| Voltage - Collector Emitter Breakdown (Max) | 40V |
| Vce Saturation (Max) @ Ib, Ic | 400mV @ 5mA, 50mA |
| Current - Collector Cutoff (Max) | 50nA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 10mA, 1V |
| Power - Max | 200mW |
| Frequency - Transition | 250MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SOT-563, SOT-666 |
| Supplier Device Package | SOT-563 |
| Base Product Number | MMDT3906 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | MMDT3904 | MMDT3904-7 | MMDT3904-7-F | MMDT3904-HF |
| Manufacturer | Good-Ark Semiconductor | Diodes Incorporated | Diodes Incorporated | Comchip Technology |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant | RoHS Compliant |
| Description | TRANS 2NPN 40V 200MA SOT-363 | TRANS 2NPN 40V 200MA SOT-363 | TRANS 2NPN 40V 200MA SOT-363 | TRANS 2NPN 40V 200MA SOT-363 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
