MP6402DN-LF
lmages are for reference only.MP6402DN-LF
IC REG LINEAR POS ADJ 8SOIC
Datasheet8-SOIC (0.154", 3.90mm Width) Exposed Pad
97,484 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Adjustable 2 Output 500mA, 500mA 8-SOICE
MP6402DN-LF
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Monolithic Power Systems Inc. |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 2 |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 0.9V |
| Voltage - Output (Max) | 3.3V |
| Voltage Dropout (Max) | 0.26V @ 500mA (Typ), 0.26V @ 500mA (Typ) |
| Current - Output | 500mA, 500mA |
| Current - Quiescent (Iq) | 580 µA |
| PSRR | 60db ~ 51dB (100Hz) |
| Control Features | Enable, Reset |
| Protection Features | Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad |
| Supplier Device Package | 8-SOICE |
| Base Product Number | MP6402 |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
 |
|
| Part Number | MP6402DN-LF-P | MP6402DN-LF-Z | MP6402DN-EF-LF | MP6402DN-EF-LF-P |
| Manufacturer | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | NRFND: USE MP6400 AS REPLACEMENT | IC REG LINEAR POS ADJ 8SOIC | IC REG LINEAR POS ADJ 500MA | NRFND: USE MP6400 AS REPLACEMENT |
| Series | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tube | Tape & Reel (TR) |
