MP6523GR-Z
lmages are for reference only.MP6523GR-Z
TRIPLE HALF-BRIDGE MOTOR DRIVER
Datasheet24-VFQFN Exposed Pad
69,186 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bipolar Motor Driver Power MOSFET Serial 24-QFN (4x4)
MP6523GR-Z
| Category | Integrated Circuits (ICs) - Power Management PMIC - Motor Drivers-Controllers |
| Manufacturer | Monolithic Power Systems Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | Brushed DC |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (3) |
| Interface | Serial |
| Technology | Power MOSFET |
| Step Resolution | - |
| Applications | Fan Motor Driver |
| Current - Output | 900mA |
| Voltage - Supply | 4.75V ~ 5.25V |
| Voltage - Load | 7V ~ 28V |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 24-VFQFN Exposed Pad |
| Supplier Device Package | 24-QFN (4x4) |
| Base Product Number | MP6523 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | MP6523GR-P | MP6523GR-P | MP6523GR-Z | MP6500AGF-P |
| Manufacturer | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TRIPLE HALF-BRIDGE MOTOR DRIVER | TRIPLE HALF-BRIDGE MOTOR DRIVER | TRIPLE HALF-BRIDGE MOTOR DRIVER | 35V, 2.5A, STEP MOTOR WITH INTER |
| Series | - | - | - | MP |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
