MP8040DN-LF
lmages are for reference only.MP8040DN-LF
IC HALF BRIDGE DRVR 4.25A 8SOICE
Datasheet8-SOIC (0.154", 3.90mm Width) Exposed Pad
91,012 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half Bridge Driver General Purpose Power MOSFET 8-SOICE
MP8040DN-LF
| Category | Integrated Circuits (ICs) - Power Management PMIC - Full Half-Bridge H Bridge Drivers |
| Manufacturer | Monolithic Power Systems Inc. |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Half Bridge |
| Applications | General Purpose |
| Interface | PWM |
| Load Type | Inductive |
| Technology | Power MOSFET |
| Rds On (Typ) | 100mOhm |
| Current - Output / Channel | 4.25A |
| Current - Peak Output | 9A |
| Voltage - Supply | 7.5V ~ 24V |
| Voltage - Load | 7.5V ~ 24V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Features | Status Flag |
| Fault Protection | Current Limiting, Over Temperature, UVLO |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad |
| Supplier Device Package | 8-SOICE |
| Base Product Number | MP8040 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | MP8040DN-LF | MP8040DN-LF-P | MP8040DN-LF-P | MP8040DN-LF-Z |
| Manufacturer | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC HALF BRIDGE DRVR 4.25A 8SOICE | IC HALF BRIDGE DRIVER 4.5A 8SOIC | IC HALF BRIDGE DRIVER 4.5A 8SOIC | IC HALF BRIDGE DRVR 4.25A 8SOICE |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
