MPQ1923GR-AEC1-Z
lmages are for reference only.MPQ1923GR-AEC1-Z
IC GATE DRVR HALF-BRIDGE 8VDFN
Datasheet8-VDFN Exposed Pad
71,408 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half-Bridge Gate Driver IC Non-Inverting 8-QFN (4x4)
MPQ1923GR-AEC1-Z
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | Monolithic Power Systems Inc. |
| Series | MPQ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Driven Configuration | Half-Bridge |
| Channel Type | Independent |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 5V ~ 17V |
| Logic Voltage - VIL, VIH | - |
| Current - Peak Output (Source, Sink) | 7A, 8A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 120 V |
| Rise / Fall Time (Typ) | 7.2ns, 5.5ns |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-VDFN Exposed Pad |
| Supplier Device Package | 8-QFN (4x4) |
| Base Product Number | - |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Product Attribute | |
 |
 |
 |
| Part Number | MPQ1923GR-AEC1-P | MPQ1922GV-AEC1-P | MPQ1922GV-AEC1-Z | MPQ1922GVE-AEC1-P |
| Manufacturer | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC GATE DRVR HALF-BRIDGE 8VDFN | IC GATE DRVR HALF-BRIDGE 22QFN | IC GATE DRVR HALF-BRIDGE 22QFN | IC GATE DRVR HALF-BRIDGE 22QFN |
| Series | MPQ | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
