MSCSM120DUM042AG
Manufacturer
Microchip TechnologyDescription
MOSFET 2N-CH 1200V 495A
Datasheet
DatasheetPackage
Module
In Stock
49,050 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MSCSM120DUM042AG
MSCSM120DUM042AG
lmages are for reference only.Payment Methods
Delivery Services
Mosfet Array 1200V (1.2kV) 495A (Tc) 2031W (Tc) Chassis Mount
Quick Inquiry
MSCSM120DUM042AG
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Technology | Silicon Carbide (SiC) |
| Configuration | 2 N-Channel (Dual) Common Source |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 1200V (1.2kV) |
| Current - Continuous Drain (Id) @ 25°C | 495A (Tc) |
| Rds On (Max) @ Id, Vgs | 5.2mOhm @ 240A, 20V |
| Vgs(th) (Max) @ Id | 2.8V @ 6mA |
| Gate Charge (Qg) (Max) @ Vgs | 1392nC @ 20V |
| Input Capacitance (Ciss) (Max) @ Vds | 18100pF @ 1000V |
| Power - Max | 2031W (Tc) |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | - |
| Base Product Number | MSCSM120 |
| Grade | - |
| Qualification | - |
