MSCSM120TAM31T3AG
Manufacturer
Microchip TechnologyDescription
MOSFET 6N-CH 1200V 89A
Datasheet
DatasheetPackage
Module
In Stock
67,834 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MSCSM120TAM31T3AG
MSCSM120TAM31T3AG
lmages are for reference only.Payment Methods
Delivery Services
Mosfet Array 1200V (1.2kV) 89A (Tc) 395W (Tc) Chassis Mount
Quick Inquiry
MSCSM120TAM31T3AG
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Technology | Silicon Carbide (SiC) |
| Configuration | 6 N-Channel (3-Phase Bridge) |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 1200V (1.2kV) |
| Current - Continuous Drain (Id) @ 25°C | 89A (Tc) |
| Rds On (Max) @ Id, Vgs | 31mOhm @ 40A, 20V |
| Vgs(th) (Max) @ Id | 2.8V @ 3mA |
| Gate Charge (Qg) (Max) @ Vgs | 232nC @ 20V |
| Input Capacitance (Ciss) (Max) @ Vds | 3020pF @ 1000V |
| Power - Max | 395W (Tc) |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | - |
| Base Product Number | MSCSM120 |
| Grade | - |
| Qualification | - |
