MSL1060AW
lmages are for reference only.MSL1060AW
IC LED DRV RGLTR PWM 30MA 24TQFN
Datasheet24-WQFN Exposed Pad
33,482 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 6 Output DC DC Regulator Step-Up (Boost) Analog, PWM Dimming 30mA 24-TQFN (5x5)
MSL1060AW
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Regulator |
| Topology | Step-Up (Boost) |
| Internal Switch(s) | Yes |
| Number of Outputs | 6 |
| Voltage - Supply (Min) | 4.75V |
| Voltage - Supply (Max) | 36V |
| Voltage - Output | 48V |
| Current - Output / Channel | 30mA |
| Frequency | 1.1MHz |
| Dimming | Analog, PWM |
| Applications | Backlight |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 24-WQFN Exposed Pad |
| Supplier Device Package | 24-TQFN (5x5) |
| Base Product Number | MSL1060 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | MSL1060AW | MSL1060AW-R | MSL1061AV | MSL1061AV-R |
| Manufacturer | Atmel | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC LED DRV RGLTR PWM 30MA 24TQFN | IC LED DRV RGLTR PWM 30MA 24TQFN | IC LED DRV RGLTR PWM 30MA 28TQFN | IC LED DRV RGLTR PWM 30MA 28TQFN |
| Series | - | - | - | - |
| Packaging | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
