MSMCG100A
lmages are for reference only.MSMCG100A
TVS DIODE 100VWM 162VC SMCG
DatasheetDO-215AB, SMC Gull Wing
86,508 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
162V Clamp 9.3A Ipp Tvs Diode Surface Mount DO-214AB (SMCG)
MSMCG100A
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Type | Zener |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 100V |
| Voltage - Breakdown (Min) | 111V |
| Voltage - Clamping (Max) @ Ipp | 162V |
| Current - Peak Pulse (10/1000µs) | 9.3A |
| Power - Peak Pulse | 1500W (1.5kW) |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | DO-215AB, SMC Gull Wing |
| Supplier Device Package | DO-214AB (SMCG) |
| Base Product Number | SMCG100 |
| Unidirectional Channels | 1 |
| Grade | Military |
| Qualification | MIL-PRF-19500 |
| Product Attribute |  |
 |
 |
|
| Part Number | MSMCG100AE3 | MSMCG100CA | MSMCG100CAE3 | MSMCG10A |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | TVS DIODE 100VWM 162VC SMCG | TVS DIODE 100VWM 162VC SMCG | TVS DIODE 100VWM 162VC SMCG | TVS DIODE 10VWM 17VC SMCG |
| Series | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| Packaging | Bulk | Bulk | Bulk | Bulk |
