Product CatalogPart Number
MSS6132T-333MLC
Manufacturer
CoilcraftDescription
FIXED IND 33UH 1.6A 250MOHM SM
Datasheet
DatasheetPackage
Nonstandard
In Stock
66,520 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MSS6132T-333MLC
MSS6132T-333MLC
lmages are for reference only.Payment Methods
Delivery Services
33 µH Shielded Drum Core Inductor 1.6 A 250mOhm Max Nonstandard
Quick Inquiry
MSS6132T-333MLC
Specifications
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Coilcraft |
| Series | MSS6132T |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Drum Core |
| Material - Core | Ferrite |
| Inductance | 33 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 1.6 A |
| Current - Saturation (Isat) | 1.1A |
| Shielding | Shielded |
| DC Resistance (DCR) | 250mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 18MHz |
| Ratings | AEC-Q200 |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.240" L x 0.240" W (6.10mm x 6.10mm) |
| Height - Seated (Max) | 0.126" (3.20mm) |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | MSS6132T-103MLC | MSS6132T-104MLC | MSS6132T-123MLC | MSS6132T-153MLC |
| Manufacturer | Coilcraft | Coilcraft | Coilcraft | Coilcraft |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 10UH 2.5A 70MOHM SM | FIXED IND 100UH 690MA 660MOHM SM | FIXED IND 12UH 2.35A 79MOHM SM | FIXED IND 15UH 2.2A 106MOHM SM |
| Series | Coilcraft | Coilcraft | Coilcraft | Coilcraft |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
