MUX509IDR
lmages are for reference only.MUX509IDR
IC SWITCH SP4T X 2 170OHM 16SOIC
Datasheet16-SOIC (0.154", 3.90mm Width)
51,034 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2 Circuit IC Switch 4:1 170Ohm 16-SOIC
MUX509IDR
| Category | Integrated Circuits (ICs) - Interface - Analog Switches-Multiplexers-Demultiplexers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Switch Circuit | SP4T |
| Multiplexer/Demultiplexer Circuit | 4:1 |
| Number of Circuits | 2 |
| On-State Resistance (Max) | 170Ohm |
| Channel-to-Channel Matching (ΔRon) | 2.4Ohm |
| Voltage - Supply, Single (V+) | 10V ~ 36V |
| Voltage - Supply, Dual (V±) | ±5V ~ 18V |
| Switch Time (Ton, Toff) (Max) | 136ns, 75ns |
| -3db Bandwidth | - |
| Charge Injection | 0.3pC |
| Channel Capacitance (CS(off), CD(off)) | 2.4pF, 4.3pF |
| Current - Leakage (IS(off)) (Max) | 1nA |
| Crosstalk | -96dB @ 1MHz |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SOIC |
| Base Product Number | MUX509 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | MUX509ID | MUX509ID | MUX509IDR | MUX509IPW |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC SWITCH SP4T X 2 170OHM 16SOIC | IC SWITCH SP4T X 2 170OHM 16SOIC | IC SWITCH SP4T X 2 170OHM 16SOIC | IC SWITCH SP4TX2 170OHM 16TSSOP |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
