NACZ330M35V6.3X6.3TR13F
lmages are for reference only.NACZ330M35V6.3X6.3TR13F
CAP ALUM 33UF 20% 35V SMD
DatasheetRadial, Can - SMD
90,334 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
33 µF 35 V Aluminum Electrolytic Capacitors Radial, Can - SMD 1000 Hrs @ 105°C
NACZ330M35V6.3X6.3TR13F
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | NIC Components Corp |
| Series | NACZ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | RoHS Compliant |
| Capacitance | 33 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 80.5 mA @ 100 Hz |
| Ripple Current @ High Frequency | 230 mA @ 100 kHz |
| Lead Spacing | - |
| Size / Dimension | 0.248" Dia (6.30mm) |
| Height - Seated (Max) | 0.248" (6.30mm) |
| Surface Mount Land Size | 0.260" L x 0.260" W (6.60mm x 6.60mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Base Product Number | - |
| Impedance | 440 mOhms |
| Product Attribute |  |
 |
 |
 |
| Part Number | NACE100M16V4X5.5TR13F | NACE100M35V5X5.5TR13F | NACE100M50V6.3X5.5TR13F | NACE101M16V6.3X5.5TR13F |
| Manufacturer | NIC Components Corp | NIC Components Corp | NIC Components Corp | NIC Components Corp |
| RoHS Status | RoHS Compliant | ROHS3 Compliant | RoHS Compliant | RoHS Compliant |
| Description | CAP ALUM 10UF 20% 16V SMD | CAP ALUM 35V POLAR | CAP ALUM 10UF 20% 50V SMD | CAP ALUM 100UF 20% 16V SMD |
| Series | NIC Components Corp | NIC Components Corp | NIC Components Corp | NIC Components Corp |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
