7A Gate Driver Capacitive Coupling 2500Vrms 1 Channel 8-SOIC
NCD57084DR2G
| Category | Isolators - Isolators Gate Drivers - |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | Capacitive Coupling |
| Number of Channels | 1 |
| Voltage - Isolation | 2500Vrms |
| Common Mode Transient Immunity (Min) | 100kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 90ns, 90ns |
| Pulse Width Distortion (Max) | 25ns |
| Rise / Fall Time (Typ) | 10ns, 15ns |
| Current - Output High, Low | 7A, 7A |
| Current - Peak Output | 7A |
| Voltage - Forward (Vf) (Typ) | - |
| Voltage - Output Supply | 12V ~ 30V |
| Grade | - |
| Qualification | - |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Approval Agency | VDE |
| Base Product Number | NCD57084 |
| Current - DC Forward (If) (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | NCD57000DWR2G | NCD57001DWR2G | NCD57001FDWR2G | NCD57080ADR2G |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DGTL ISO 5KV 1CH GATE DVR 16SOIC | DGTL ISO 5KV 1CH GATE DVR 16SOIC | DGTL ISO 5KV 1CH GATE DVR 16SOIC | DGTL ISO 3.75KV 1CH GT DVR 8SOIC |
| Series | onsemi | onsemi | onsemi | onsemi |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
