NCP1070STCT3G
Manufacturer
onsemiDescription
IC OFFLINE SWITCH FLYBACK SOT223
Datasheet
DatasheetPackage
TO-261-4, TO-261AA
In Stock
42,724 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
NCP1070STCT3G
NCP1070STCT3G
lmages are for reference only.Payment Methods
Delivery Services
Converter Offline Flyback Topology 130kHz SOT-223 (TO-261)
Quick Inquiry
NCP1070STCT3G
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | 6.3V ~ 10V |
| Duty Cycle | 68% |
| Frequency - Switching | 130kHz |
| Power (Watts) | 14 W |
| Fault Protection | Over Load, Over Temperature, Over Voltage, Short Circuit |
| Control Features | - |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Package / Case | TO-261-4, TO-261AA |
| Supplier Device Package | SOT-223 (TO-261) |
| Mounting Type | Surface Mount |
| Base Product Number | NCP1070 |
| Voltage - Start Up | 8.2 V |
| Grade | - |
| Qualification | - |
