Converter Offline Flyback Topology 65kHz 8-PDIP
NCP1077BAP065G
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | 6.5V ~ 20V |
| Duty Cycle | 68% |
| Frequency - Switching | 65kHz |
| Power (Watts) | 31 W |
| Fault Protection | Current Limiting, Over Power, Over Temperature, Over Voltage, Short Circuit |
| Control Features | - |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Package / Case | 8-DIP (0.300", 7.62mm), 7 Leads |
| Supplier Device Package | 8-PDIP |
| Mounting Type | Through Hole |
| Base Product Number | NCP1077 |
| Voltage - Start Up | 8.4 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | NCP1077BAP100G | NCP1077BAP130G | NCP1077BBP065G | NCP1077BBP100G |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC OFFLINE SWITCH FLYBACK 8DIP | IC OFFLINE SWITCH FLYBACK 8DIP | IC OFFLINE SWITCH FLYBACK 8DIP | IC OFFLINE SWITCH FLYBACK 8DIP |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
