NCP623DM-33R2
lmages are for reference only.Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 150mA 8-MSOP
NCP623DM-33R2
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS non-compliant |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 12V |
| Voltage - Output (Min/Fixed) | 3.3V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.26V @ 150mA |
| Current - Output | 150mA |
| Current - Quiescent (Iq) | 200 µA |
| PSRR | 70dB (1kHz) |
| Control Features | Enable |
| Protection Features | Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 8-MSOP |
| Base Product Number | NCP623 |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | NCP623DM-33R2G | NCP623DM-40R2 | NCP623DM-40R2G | NCP623DM-50R2 |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ||
| Description | IC REG LINEAR 3.3V 150MA MICRO8 | IC REG LINEAR 4V 150MA MICRO8 | IC REG LINEAR 4V 150MA MICRO8 | IC REG LINEAR 5V 150MA MICRO8 |
| Series | onsemi | onsemi | onsemi | onsemi |
| Packaging | Tape & Reel (TR) | Bulk | Tape & Reel (TR) | Tape & Reel (TR) |
