Gate Driver Capacitive Coupling 1200Vrms 1 Channel 16-SOIC
NCV57000DWR2G
| Category | Isolators - Isolators Gate Drivers - |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | Capacitive Coupling |
| Number of Channels | 1 |
| Voltage - Isolation | 1200Vrms |
| Common Mode Transient Immunity (Min) | 100kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 90ns, 90ns |
| Pulse Width Distortion (Max) | - |
| Rise / Fall Time (Typ) | 10ns, 15ns |
| Current - Output High, Low | 7.8A, 7.1A |
| Current - Peak Output | - |
| Voltage - Forward (Vf) (Typ) | - |
| Voltage - Output Supply | 0V ~ 24V |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 16-SOIC |
| Approval Agency | UL, VDE |
| Base Product Number | NCV57000 |
| Current - DC Forward (If) (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | NCV57001DWR2G | NCV57001FDWR2G | NCV51152BADR2G | NCV51152CADR2G |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DGTL ISO 1.2KV 1CH GT DVR 16SOIC | DGTL ISO 1.2KV 1CH GT DVR 16SOIC | ISOLATED SINGLE CHANNEL GATE DRI | ISOLATED SINGLE CHANNEL GATE DRI |
| Series | onsemi | onsemi | onsemi | onsemi |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
