Product CatalogPart Number
NE685M13-A
Manufacturer
CELDescription
RF TRANS NPN 6V 12GHZ M13
Datasheet
DatasheetPackage
SOT-3
In Stock
71,004 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
NE685M13-A
NE685M13-A
lmages are for reference only.Payment Methods
Delivery Services
RF Transistor NPN 6V 30mA 12GHz 140mW Surface Mount M13
Quick Inquiry
NE685M13-A
Specifications
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | CEL |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Transistor Type | NPN |
| Voltage - Collector Emitter Breakdown (Max) | 6V |
| Frequency - Transition | 12GHz |
| Noise Figure (dB Typ @ f) | 1.5dB ~ 2.5dB @ 2GHz |
| Gain | - |
| Power - Max | 140mW |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 75 @ 10mA, 3V |
| Current - Collector (Ic) (Max) | 30mA |
| Operating Temperature | 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | SOT-3 |
| Supplier Device Package | M13 |
| Base Product Number | NE685 |
