NFL18SP307X1A3D
lmages are for reference only.NFL18SP307X1A3D
FILTER LC(PI) 60NH/19PF SMD
Datasheet0603 (1608 Metric), 3 PC Pad
84,798 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LC (Pi) EMI Filter 3rd Order Low Pass 1 Channel L = 60nH, C = 19pF 100 mA 0603 (1608 Metric), 3 PC Pad
NFL18SP307X1A3D
| Category | Filters - EMI-RFI Filters LC-RC Networks - |
| Manufacturer | Murata Electronics |
| Series | EMIFIL®, NFL18 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Low Pass |
| Filter Order | 3rd |
| Technology | LC (Pi) |
| Center / Cutoff Frequency | 300MHz (Cutoff) |
| Attenuation Value | - |
| Resistance - Channel (Ohms) | - |
| Current | 100 mA |
| Values | L = 60nH, C = 19pF |
| ESD Protection | No |
| Operating Temperature | -55°C ~ 125°C |
| Applications | General Purpose |
| Voltage - Rated | 10V |
| Mounting Type | Surface Mount |
| Package / Case | 0603 (1608 Metric), 3 PC Pad |
| Size / Dimension | 0.063" L x 0.032" W (1.60mm x 0.80mm) |
| Height | 0.028" (0.70mm) |
| Number of Channels | 1 |
| Base Product Number | NFL18SP |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | NFL18SP307X1A3D | NFL18SP157X1A3D | NFL18SP157X1A3D | NFL18SP207X1A3D |
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics | Murata Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FILTER LC(PI) 60NH/19PF SMD | FILTER LC(PI) 100NH/34PF SMD | FILTER LC(PI) 100NH/34PF SMD | FILTER LC(PI) 80NH/24PF SMD |
| Series | EMIFIL®, NFL18 | EMIFIL®, NFL18 | EMIFIL®, NFL18 | EMIFIL®, NFL18 |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
