NJG1103F1-TE1
lmages are for reference only.NJG1103F1-TE1
IC AMP TDMA 1.4-1.52GHZ SOT23-6
DatasheetSOT-23-6
38,360 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RF Amplifier IC TDMA 1.4GHz ~ 1.52GHz, 1.89GHz ~ 1.92GHz SOT-23-6-1
NJG1103F1-TE1
| Category | RF and Wireless - RF Amplifiers - |
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS non-compliant |
| Frequency | 1.4GHz ~ 1.52GHz, 1.89GHz ~ 1.92GHz |
| P1dB | -6dBm ~ -2dBm |
| Gain | 14dB ~ 18dB |
| Noise Figure | 1.2dB ~ 1.4dB |
| RF Type | TDMA |
| Voltage - Supply | 2.5V ~ 4.5V |
| Current - Supply | 3mA ~ 3.8mA |
| Test Frequency | 1.489GHz |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-6 |
| Supplier Device Package | SOT-23-6-1 |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | NJG1103F1-TE1# | NJG1101F-TE1 | NJG1101F-TE1# | NJG1105F-TE1 |
| Manufacturer | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. |
| RoHS Status | RoHS Compliant | RoHS non-compliant | RoHS Compliant | RoHS non-compliant |
| Description | IC AMP TDMA 1.4-1.52GHZ SOT23-6 | IC AMP TDMA 850MHZ-2.5GHZ SOT23 | IC AMP TDMA 850MHZ-2.5GHZ SOT23 | IC AMP CEL 1.8/1.9/2.1GHZ 6MTP |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
