NJU8721V-TE1
lmages are for reference only.NJU8721V-TE1
IC AMP CLASS D STER 80MW 20SSOP
Datasheet20-LSSOP (0.173", 4.40mm Width)
79,142 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Amplifier IC Headphones, 2-Channel (Stereo) Class D 20-SSOP
NJU8721V-TE1
| Category | Integrated Circuits (ICs) - Linear - Amplifiers |
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS non-compliant |
| Type | Class D |
| Output Type | Headphones, 2-Channel (Stereo) |
| Max Output Power x Channels @ Load | 80mW x 2 @ 8Ohm |
| Voltage - Supply | 2.4V ~ 3.6V |
| Features | Digital Inputs, I2S, Mute, PWM, Standby |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Supplier Device Package | 20-SSOP |
| Package / Case | 20-LSSOP (0.173", 4.40mm Width) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | NJU8725V-TE1 | NJU8725V-TE1# | NJM2070D | NJM2073D |
| Manufacturer | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. |
| RoHS Status | RoHS non-compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | IC AMP CLASS D QUAD 800MW 24SSOP | IC AMP CLASS D QUAD 800MW 24SSOP | IC AMP CLASS AB MONO 600MW 8DIP | IC AMP CLSS AB MONO/STER 2W 8DIP |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tube | Tube |
