NJW4184DL3-08A-TE2
lmages are for reference only.NJW4184DL3-08A-TE2
IC REG LINEAR 8V 300MA TO252-5
DatasheetTO-252-6, DPAK (5 Leads + Tab)
56,168 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 300mA TO-252-5
NJW4184DL3-08A-TE2
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 35V |
| Voltage - Output (Min/Fixed) | 8V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.1V @ 100mA |
| Current - Output | 300mA |
| Current - Quiescent (Iq) | 12 µA |
| PSRR | 33dB (1kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-6, DPAK (5 Leads + Tab) |
| Supplier Device Package | TO-252-5 |
| Base Product Number | NJW4184 |
| Current - Supply (Max) | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | NJW4184DL3-05A-TE2 | NJW4184DL1-05B-TE2 | NJW4184DL1-15B-TE2 | NJW4184DL1-25B-TE2 |
| Manufacturer | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. |
| RoHS Status | ||||
| Description | IC REG LINEAR 5V 300MA TO252-5 | IC REG LINEAR 5V 300MA TO252-3 | IC REG LINEAR 15V 300MA TO252-3 | IC REG LINEAR 2.5V 300MA TO252-3 |
| Series | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
