Product CatalogPart Number
NUP3105LT1G
Manufacturer
onsemiDescription
TVS DIODE 32VWM 66VC SOT23-3
Datasheet
DatasheetPackage
TO-236-3, SC-59, SOT-23-3
In Stock
88,723 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
NUP3105LT1G
NUP3105LT1G
lmages are for reference only.Payment Methods
Delivery Services
66V Clamp 8A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
Quick Inquiry
NUP3105LT1G
Specifications
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | 2 |
| Voltage - Reverse Standoff (Typ) | 32V (Max) |
| Voltage - Breakdown (Min) | 35.6V |
| Voltage - Clamping (Max) @ Ipp | 66V |
| Current - Peak Pulse (10/1000µs) | 8A (8/20µs) |
| Power - Peak Pulse | 350W |
| Power Line Protection | No |
| Applications | CAN |
| Capacitance @ Frequency | 30pF @ 1MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 (TO-236) |
| Base Product Number | NUP3105 |
| Unidirectional Channels | - |
| Grade | Automotive |
| Qualification | AEC-Q101 |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | NUP3105L | NUP3105L-AQ | NUP3105LT3G | NUP3112UPMUTAG |
| Manufacturer | Diotec Semiconductor | Diotec Semiconductor | onsemi | onsemi |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | TVS DIODE 32VWM 70VC SOT-23-3 | TVS DIODE 32VWM 70VC SOT-23-3 | TVS DIODE 32VWM 66VC SOT23-3 | TVS DIODE 4VWM 6UDFN |
| Series | Diotec Semiconductor | Diotec Semiconductor | onsemi | onsemi |
| Packaging | Bulk | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
